Description
MAIN PERFORMANCE AND STRUCTURE FEATURES:
- Double transducer control, flexible bag length cutting, operator no need to adjust the unloading working, saving time and saving films.
2. human-machine operation, convenient and quick parameter setting.
3. Self-diagnosis failure function, clear failure display.
4. High sensitivity optical electric colour mark tracking, digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. All the controls are achieved by software, convenient for function adjusting and upgrading.
TECHNICAL PARAMETER:
| Model | IA-600X/KT |
| Film width | Max 600mm |
| Bag length | 120-500mm |
| Bag width | 100-280 |
| Product height | Max 110mm |
| Packaging rate | 20-150 bag/min |
| Power | 220v 50/60Hz |
| Machine size (L x W x H) | 4020 x 920 x 1460mm |
| Machine weight | About 680kg |
| Film roll diameter | Max 320mm |
