Description
FEATURES:
- Double transducer control, flexible bag length cutting, operator no need to adjust the unloading working, saving time and saving films.
- human-machine operation, convenient and quick parameter setting.
- Self-diagnosis failure function, clear failure display.
- High sensitivity optical electric colour mark tracking, digital input cut position which makes the sealing and cutting more accurate.
- Separate PID control to temperature, suitable for various packing materials.
- Stopping the machine in selected position, no sticking to the knife and no waste packing film.
- Simple driving system, reliable working, convenient maintenance.
- All the controls are achieved by software, convenient for function adjusting and upgrading.
SCOPE:
Suitable for biscuits, rice, snow cake, pie, chocolate, bread, instant noodles, moon cake, medicines, daily necessities, industrial parts, paper boxes or pallets and another packing regular object.
TECHNICAL PARAMETER:
| Model | IA-250N/HDL |
| Brand | IACHIEVE |
| Film width | Max.250mm |
| Bag length | 120-280mm |
| Bag width | 30-110mm |
| Product height | Max.40mm |
| Film roll diameter | Max.320mm |
| Packing speed | 40-150 bags/min |
| Power specification | 220v, 50/60Hz, 2.4kw |
| Machine size (L x W x H) | 3000 x 670 x 1450mm |
| Quality machine approximately | 650kg |
