Description
FEATURES:
- Double transducer control, flexible bag length cutting, operator no need to adjust the unloading working, saving time and saving films.
- human-machine operation, convenient and quick parameter setting.
- Self-diagnosis failure function, clear failure display.
- High sensitivity optical electric colour mark tracking, digital input cut position which makes the sealing and cutting more accurate.
- Separate PID control to temperature, suitable for various packing materials.
- Stopping the machine in selected position, no sticking to the knife and no waste packing film.
- Simple driving system, reliable working, convenient maintenance.
- All the controls are achieved by software, convenient for function adjusting and upgrading.
MACHINE SPECIFICATION:
| Film Width | Max 400mm |
| Bag Length | 150 – 400mm |
| Bag Width | 50-180mm |
| Product Height | Max 65mm |
| Film Roll Diameter | Max 320mm |
| Packaging Speed | 30-150 bag/min ( according to the product condition ) |
| Power | 220v 50/60Hz 2.8kw |
| Machine Size ( LxWxH ) | 4020 x 800 x 1450mm |
| Machine Weight | About 700kg |
