Description
INTRODUCTION:
The soap film packing machine is suitable for various shape of soap, and it can pack different size of soap directly without changing the mould. Besides, one person can operate two sets of film soap packing machine at the same time, which can save much more labor and improve the productivity. This machine is convenient and easy to operate. It is drive by air cylinder, and runs smoothly and continuously, and the packing effect is excellent. Packing film is stretched and formed automatically, also have the auto-shrinking function. This transparent film wrapping machine adopts traditional system which is reliable, very easy to operate and maintain.
FEATURES:
- The machine adopts pneumatic cylinder drive, compact smooth operation, the packaging effect is good.
- The packaging film automatic stretch forming. Automatic recovery.
- Automatic convergent welding.
- Replace packaging different shape without the size of the soap mold (except for very specific).
- Drive system is simple, reliable operation, maintenance more convenient.
- Automatic feeding and discharging conveyor belt.
- Packing speed is adjustable 12-20pcs/min.
TECHNICAL PARAMETER:
| Model | IA-20/XZJ | |
| Packing speed | 12-20pcs/min | |
| Soap range | Diameter | ≥40mm |
| Thickness | ≤30mm | |
| Film specifications | Film out diameter | ≤φ200mm |
| Film width | ≤260mm | |
| Film inner drum dia. | φ≤75mm | |
| Film thickness | 0.02mm | |
| Power | 180w | |
| Voltage | 220V | |
| Pressure | 5-7kg/cm3 | |
| Weight | 220KG | |
| Dimension | 3000*1100*1650mm(L*W*H) | |
