Description
MACHINE OVERVIEW:
This machine is a new desktop automatic sealing machine developed according to market demand, which improves production efficiency and saves effort. The sealing film is made of plastic composite coils, automatic punching, automatic sealing and automatic waste discharge, which solves some cups without lids. , The bottle sealing problem, no matter what shape, can be sealed, saving space, can seal one box, two boxes, four boxes at a time, it is very popular among users.
SPECIFICATION:
- Automatic box feeding, air pressure sealing, automatic waste discharge, automatic box ejection, automatic top box.
- Single-chip microcomputer program control, stable and reliable.
- The man-machine interface is controlled by a touch screen, which is easy to operate and can monitor the running status of the machine at any time.
- Classic digital display temperature control meter, the temperature difference is plus or minus 5 degrees, and the sealing effect is good.
- Precise guide rail, smooth walking and precise positioning.
- Taiwan photoelectric eye tracking, electrical integration.
TECHNICAL PARAMETER:
| Model | IA-802/1T |
| Production Speed | One out of one : 500 boxes/hour |
| Sealing Diameter | 30-250mm ( Can be customized ) |
| Sealing Material | Plastic composite film, aluminum foil composite film, PP, PVC, PE, PET, PS are all available |
| The Size of the Sealing Film | 2-3mm large than the cup mouth, with tight sealing and beautiful apperance |
| Air pressure range | 4-8kg/cm2 |
| Temperature Range | 0-300 degrees |
| Power | 500-1000w |
| Voltage | 200v |
| Machine Size | 1400 x 850 x650 |
| Machine Apperance | Stainless steel |
| Net Weight | 85kg |
PRODUCT APPLICATION:
