Description
FEATURES:
- Double transducer control, flexible bag length cutting, operator no need to adjust the unloading working, saving time and saving films.
2. human-machine operation, convenient and quick parameter setting.
3. Self-diagnosis failure function, clear failure display.
4. High sensitivity optical electric colour mark tracking, digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. All the controls are achieved by software, convenient for function adjusting and upgrading.
SCOPE:
Suitable for biscuits, rice, snow cake, pie, chocolate, bread, instant noodles, moon cake, medicines, daily necessities, industrial parts, paper boxes or pallets and another packing regular object.
TECHNICAL PARAMETER:
| Model | IA-250Z/HDL |
| Bag length (mm) | 50-150 |
| Bag width (mm) | 50-120 |
| Product height (mm) | Max 40 |
| Machine motion | Continuous type |
| Machine control through | Panasonic PLC |
| Machine speed | 50-100 bag/min |
| Film width | Max 250mm |
| Film roll diameter | Max 320mm |
| Packing film | Any heat sealable laminated roll |
| Power | 220v 50/60Hz 2.4kw |
| Dimension (L x W x H) mm | 3770 x 670 x 1450mm |
| Weight | About 700kg |
