Description
DESCRIPTION:
1. Measuring system adopt volumetric cup measuring system, which is used to adjust material content during operation of the machine.2. Adopt PLC and touchable screen or microcomputer, Chinese and English surface.3. Equipped with Schneider frequency converter, just input number to change the whole speed, easy for operation.4. Use double heating tubes to guarantee stable temperature and perfect sealing surface, intelligent temperature controller, and stable color mark tracking system, increase the cutting precision.5. Capacity to program Data for 10 products.6. Independent temperature control system, accuracy up to ±1℃, which makes it possible to use various packaging film.7. All the work of bag making, measuring, filling, sealing, cutting, counting, heat-printing codes can be done automatically.8. Closed frame construction, made of stainless steel 304.9. Environmental, low noise and clean working area.
TECHNICAL PARAMETER:
| Bag Size | L: 30-180mm W: 20-230mm |
| Packing Speed | 20-70 bags/minute |
| Measuring Range | 5-30ml |
| Voltage Power | 220V, 50Hz/60Hz, 2kw |
| Machine Weight | 350kgs |
| Package Dimension | 1000 x 950 x 1800mm |
| Volume | 20-40ml |
| Capacity | 40-80pcs/min |
| Bag Shape | 4 Sealing bag |
EQUIPMENT PRODUCTION PROCESS:
