Description
FEATURES:
- Double transducer control, flexible bag length cutting, operator no need to adjust the unloading working, saving time and saving films.
- human-machine operation, convenient and quick parameter setting.
- Self-diagnosis failure function, clear failure display.
- High sensitivity optical electric colour mark tracking, digital input cut position which makes the sealing and cutting more accurate.
- Separate PID control to temperature, suitable for various packing materials.
- Stopping the machine in selected position, no sticking to the knife and no waste packing film.
- Simple driving system, reliable working, convenient maintenance.
- All the controls are achieved by software, convenient for function adjusting and upgrading.
SCOPE:
Suitable for biscuits, rice, snow cake, pie, soap, chocolate, bread, instant noodles, moon cake, medicines, daily necessities, industrial parts, paper boxes or pallets and other packing regular object.
SPECIFICATION:
| Model No | IA-350D/HDL | IA-450D/HDL | IA-600D/HDL |
| Bag Length (Mm) | 110-330 | 120-450 | 120-450 |
| Bag Width (Mm) | 30-130 | 50-160 | 50-200 |
| Produce Height(Mm) | 10-60 | 50-100(MAX) | 10-80 |
| Film Width(Mm) | Max.350 | Max.450 | Max.600 |
| Power | 220V.50/60Hz.2.4Kw | 220V.50/60Hz.3.2Kw | 220V.50/60Hz.3.6Kw |
| Machine Size (Mm) | L3670*H820*H1410 | L4380*H870*H1500 | L4380*H970*H1500 |
| Machine Weight(Kg) | 750 | 900 | 1100 |
| Machine Speed | 30-120 | 20-80 | |
| Film Roll Diameter | Max.320 | ||
| Packing Film | Any Heat Sealable Laminated Roll | ||
| Machine Motion | Continuous Type | ||
| Machine Control Through | PANASONIC PLC | ||
| Product Application | Packaging Regular Objects:Biscuit, Soap,Pies, Plates,Etc | ||
| Packing Film Pulling | Through Electromagnetic Clutch And Brake | ||
| Contact Parts | Food Grade Stainless Ss 304 | ||
| Sealing Type | Pillow Bag | ||
| Main Motor | Panasonic | ||
