Description
PERFOMANCE FEATURES:
- Photoelectric switch, automatically sensing the length of the packaging.
- Adopt imported cylinder, make the pushing cutting more smoothly.
- Sealing system installed anti-cutting protection device to increase equipment safety.
- Sealing knife uses the aluminum knife with DuPont Teflon which is anti-stick coating & anti-high temperature. So the sealing will not have cracking, coking smoking with zero pollution.
- Use imported electrical components, reduce the failure in using.
- Packaging different shape specification products, the front positioning frame can be adjusted.
- Automatic manual can switch at any time.
SPECIFICATION:
| Model | IA-6030/AZ | IA-6040/E |
| Power | 2kw | 18kw |
| Power Supply | AC220V 1/3 PH 50/60Hz | AC220V/380 3 PH 50/60Hz |
| Max Packing Size L×W×H | L(unlimited)×500×300mm | W500×H350mm |
| Tunnel Size L×W×H | / | 1800×600×400mm |
| Blade Length | 670mm | / |
| Air Temperature | 0-300℃ | 0-300℃ |
| Table Height | 820±50mm | 820±50mm |
| Packing Speed | 25m/min. | 0-25m/min |
| External Air Source | 6-8kg/cm2 | / |
| Shrink Film | PE | PE |
| Machine Size L×W×H | 950×950×1865mm | 2800×950×1750mm |
| Packaging Size L×W×H | 1000×1000×2015mm | 2850×1000×1900mm |
| G./N. Weight | 420/380kgs | 625/565kgs |
