Description
FEATURES:
- The procedure of plastic film packing from feeding, sealing, to shrinking is operated automatically. It fits for automatic production effect.
- The Auto L-type sealer is available for various kinds of films such as OPP, PP, PE, and POF film.
- We can choose vertical photoelectric cell or horizontal photoelectric cell according to size of product.
- Labor cost saving. All you need to do is to load the product onto the in-feed conveyor.
- Energy saving and shorten the working hours.
- Easy adjustment, maintenance and operation.
- Auto scrap film collector helps decreasing cost and beautifies the working environment. The film scrap takes up drum can be taken apart from the collector easily.
- There is no smoke produced when sealing or cutting.
TECHNICAL PARAMETER L-TYPE SEALER:
| Model | IA-4550A/CHL |
| Power | 220V/240V Single phase |
| Power consumption | 1.5kw |
| Sealing frame size (L x W x H) | 500 x 450 x 120mm |
| Conveyor speed | 0-18m/min |
| Conveyor size | W=370mm |
| Working table height | H=800+50mm |
| Machine size (L x W x H) | 1600 x 950 x 1450mm |
TECHNICAL PARAMETER SHRINK TUNNEL:
| Model | IA-4520A |
| Power | 220V/240V Single phase |
| Power consumption | 6kw |
| Tunnel size (L x W x H) | 800 x 450 x 200mm |
| Packaging speed | 0-10m/min |
| Conveyor size (L x W) | 1200 x 450mm |
| Machine size (L x W x H) | 1330 x 720 x 1100mm |
